RC 6Chemistry-HYBRID pump
Overview
- reduced internal corrosion, even when working with corrosive vapors
- oil changes typically reduced 90% or more compared with rotary vane pumps alone
- most economical solution: In practical operation a cold trap is often no longer necessary
- ease of maintenance due to telescopic design
Ultimate vacuum
2 x 10-3 mbar
Ultimate vacuum with gas ballast
1 x 10-2 mbar
Max. pumping speed 50 Hz
5.9 m3/h
Chemistry-HYBRID pump in action
The RC 6 chemistry-HYBRID pump is a combination of a two-stage rotary vane pump and a two-stage chemistry diaphragm pump for optimized corrosion resistance. The diaphragm pump maintains the oil reservoir under vacuum in order to keep the partial pressures of solvent vapors at levels below their condensation points and to reduce largely the concentration of oxygen and corrosive gases. Therefore the RC 6 chemistry-HYBRID pump has a much higher solvent vapor pumping capability and resistance to aggressive gases than conventional rotary vane pumps.
Technical data and graphs
| Max. pumping speed 50 Hz | 5.9 m3/h | Select diagram |
| Max. pumping speed 60 Hz | 4.1 cfm | Select diagram |
| Ultimate partial vacuum (abs.) without gas ballast | 4 x 10-4 mbar | |
| Ultimate vacuum | 2 x 10-3 mbar / 1.5 x 10-3 torr | |
| Ultimate vacuum with gas ballast | 1 x 10-2 mbar / 0.75 x 10-2 torr | |
| Number of heads | 2 | |
| Number of stages | 2 + 2 | |
| Water vapor tolerance with gas ballast | >> 40 mbar | |
| Lower ambient temperature (operation) | 12 °C | |
| Upper ambient temperature (operation) | 40 °C | |
| Lower ambient temperature (storage) | -10 °C | |
| Upper ambient temperature (storage) | 60 °C | |
| Max. back pressure (abs.) | 1.1 bar | |
| Oil capacity (B-Oil) min. | 0.34 l | |
| Oil capacity (B-Oil) max. | 0.50 l | |
| Inlet connection | small flange KF DN 16 | |
| Outlet connection | Hose nozzle DN 8-10 mm | |
| Rated motor power | 0.3 kW | |
| Rated motor speed at 50/60 Hz | 1500/1800 min-1 | |
| Protection class IEC 60529 | IP 40 | |
| Dimension L in mm | 526 mm | |
| Dimension B in mm | 302 mm | |
| Dimension H in mm | 226 mm | |
| Weight | 25 kg | |
| Noise (sound pressure level) in dBA at 50 Hz or 1500 rpm/62% (VARIO)/1500 rpm (VARIO-SP)/12500 Upm (VACUU·PURE®) | 50 dBA | |
| NRTL certification | No | |
| Items supplied | Pump completely mounted, ready for use after oil filling (bottle 0.5 l enclosed), with manual. | |
| Rated mains voltage range 1 | 230 V | |
| Mains frequency 1 | 50-60 Hz |
für Zoom klicken
Max. pumping speed 50 Hz
für Zoom klicken
Max. pumping speed 60 Hz
für Zoom klicken
Pump down graph 50 Hz (10 l volume)
für Zoom klicken
Pump down graph 60 Hz (10 l volume)
Downloads
Optional accessories
Related Products
Application examples
